Greptime User Guide — How to Migrate Datanode Table Partitions

Since v0.6, the distributed version of GreptimeDB has had the capability to migrate table partition (Region) data from one Datanode to another. In the previous article, we provided a detailed illustration of the specific technical details of implementing Region Migration.

This article will demonstrate how to use this feature in detail.

Prerequisites ​

Before starting, please ensure that the distributed cluster in your environment meets the following conditions; failing to meet any one of these will result in the failure of Region Migration.

• Use of Remote WAL

• Use of shared storage (e.g., AWS S3)

We will use a table named "monitor" as an example and demonstrate how to migrate a table partition (Region) to another Datanode node.

CREATE TABLE monitor (
  host STRING,
  ts TIMESTAMP DEFAULT CURRENT_TIMESTAMP() TIME INDEX,
  cpu DOUBLE DEFAULT 0,
  memory DOUBLE,
  PRIMARY KEY(host));

Write some data into the table:

INSERT INTO monitor
VALUES
    ("127.0.0.1", 1702433141000, 0.5, 0.2),
    ("127.0.0.2", 1702433141000, 0.3, 0.1),
    ("127.0.0.1", 1702433146000, 0.3, 0.2),
    ("127.0.0.2", 1702433146000, 0.2, 0.4),
    ("127.0.0.1", 1702433151000, 0.4, 0.3),
    ("127.0.0.2", 1702433151000, 0.2, 0.4);

Querying Table Partition (Region) Distribution ​

First, we need to inquire about the distribution of table partitions (Regions), that is, to find out on which Datanode nodes the Regions of the table are located.

select
    b.peer_id as datanode_id,
    a.greptime_partition_id as region_id
from
    information_schema.partitions a
    left join
    information_schema.greptime_region_peers b
    on a.greptime_partition_id = b.region_id
where a.table_name='monitor'
order by datanode_id asc;

The query results indicate that the table comprises one Region, identified by Region ID 4398046511104 and hosted on the node with Datanode ID 1.

+-------------+---------------+
| datanode_id | region_id     |
+-------------+---------------+
|           1 | 4398046511104 |
+-------------+---------------+
1 row in set (0.01 sec)

Performing Region Migration ​

We can migrate the table's Region to another node (the demonstration cluster includes 3 Datanode nodes with IDs 0, 1, and 2).

As shown below, the Region with ID 4398046511104 will be migrated to the node with Datanode ID 2.

The fourth parameter is optional and sets the Replay Timeout (secs) for the region migration, with a default value of 10 seconds. If the network bandwidth between Kafka and the Datanode is insufficient, potentially delaying the migration process, adjusting this parameter upwards may be necessary.

select migrate_region(4398046511104, 1, 2, 60);

+------------------------------------------------------------------+
| migrate_region(Int64(4398046511104),Int64(1),Int64(2),Int64(60)) |
+------------------------------------------------------------------+
| 0f65f485-2790-4bf3-8b71-74f73ef15457                             |
+------------------------------------------------------------------+
1 row in set (0.00 sec)

After initiating the migration, a Procedure ID corresponding to the migration is returned. This ID can be used to inquire about the status of migration.

Querying Migration Status ​

select procedure_state('0f65f485-2790-4bf3-8b71-74f73ef15457');

+---------------------------------------------------------------+
| procedure_state(Utf8("0f65f485-2790-4bf3-8b71-74f73ef15457")) |
+---------------------------------------------------------------+
| {"status":"Done"}                                             |
+---------------------------------------------------------------+
1 row in set (0.00 sec)

When the query returns a status of "Done," it indicates that the Procedure has been successfully completed.

Querying Post-Migration Table Region Information ​

Upon querying the Table Region information again, it can be observed that the Region has been migrated to the Datanode with ID 2.

select * from information_schema.greptime_region_peers;

+---------------+---------+--------------------------------------------------------------+-----------+--------+--------------+
| region_id     | peer_id | peer_addr                                                    | is_leader | status | down_seconds |
+---------------+---------+--------------------------------------------------------------+-----------+--------+--------------+
| 4398046511104 |       2 | greptimedb-datanode-2.greptimedb-datanode.my-greptimedb:4001 | Yes       | ALIVE  |         NULL |
+---------------+---------+--------------------------------------------------------------+-----------+--------+--------------+
1 row in set (0.02 sec)

Learn More ​

To learn more about the distributed version of GreptimeDB, we invite you to read related articles for a deeper understanding of GreptimeDB's distributed capabilities and to maximize its value.

• Deploying Distributed GreptimeDB with Helm Chart
• Kafka Remote WAL Documentation - User Guide

This article is designed to help you fully recognize and utilize the powerful features of GreptimeDB's distributed version, bringing greater convenience and benefits to data management and distributed computing. If you encounter any questions while using it, we encourage you to consult the relevant documentation for a comprehensive understanding of the system.
